Back-Sealing Powder Packaging Machine & Chemical Packaging Machine
Product Name
Back-Seal Powder Packaging Machine - Chemical Industry Packaging Machine
Company Overview
We specialize in automated packaging solutions, including flour packaging systems, foundry material packers, textured paint fillers, thixotropic agent packaging machines, and drop-type packaging equipment. Our machines are designed for high efficiency, stability, and user-friendly operation. Through continuous innovation, we deliver tailored solutions and premium services for diverse industrial needs.
Optional Configurations:
Pneumatic valve port
Ultrasonic sealing valve port
Rotor/pneumatic floating feeder
Screw valve port / Open-mouth screw feeder
Gravity valve port / Open-mouth gravity feeder
Belt-type open-mouth feeder
FIBC (ton bag) packaging
(Material-specific solutions available. Consult our sales team for details.)
Technical Specifications
| Parameter | Details |
|---|---|
| Bag Capacity | 25kg-2 tons/bag |
| Bag Types | Pillow bags, gusseted bags, perforated bags |
| Speed | 30–60 bags/minute |
| Bag Dimensions | Length: 50–460mm / Width: 80–350mm |
| Machine Weight | 1000kg |
| Power Supply | 3kW, 380V ±10%, 50Hz (3-phase) |
| Dimensions | 1420×1530×1830mm (L×W×H) |
| Air Pressure | 0.6MPa, consumption 0.36m³/min |
| Material Roll Size | Max outer diameter: φ500mm / Core inner diameter: φ75mm |
Key Features
Customized Design
Engineered for powders and granules with minimal wear parts and high durability.
Precision & Speed
Stepless speed adjustment for 30–60 bags/minute and dynamic accuracy ±0.2%.
Smart Control
Programmable PLC system with auto-tare, auto-zero, and real-time error correction.
Safety & Compliance
Explosion-proof design (optional) and integrated dust removal (≤5mg/m³).
Advanced Weighing
Digital calibration, anti-interference sensors, and cumulative weight tracking.
Operation Workflow
Startup Sequence:
Setup: Power on → Clamp bag → Elevate to weighing position.
Calibration: Auto-tare → Material pre-feed.
Filling: Rapid filling → Precision topping → Auto-seal.
Output: Conveyor transfer → Palletizing.
Applications
Industries: Cement, mining, construction, chemicals, agriculture, feed processing.
Materials: Powders, granules, adhesives, additives, fertilizers.
After-Sales Service
Warranty: 1-year full warranty, lifetime technical support.
Coverage:
Free troubleshooting and spare parts supply within warranty.
Post-warranty: 1-year extended coverage, lifetime maintenance support.
Exclusions: Damage from misuse or unauthorized modifications.
