200-Liter Transfer Palletizing Machine
Key Features:
Dual-Function Design
Transfer Mode: Seamless conveyance between production lines, filling stations, and storage areas
Palletizing Mode: Auto-stacks up to 1.2-ton loads (200L IBCs) at 450 cycles/hour
Heavy-Duty Engineering
Load Capacity: 2,000kg per layer (3-layer pallets standard)
Frame Construction: 304 stainless steel with IP65 washdown rating
Drive System: Servo-motor precision with 0.1mm positioning accuracy
Smart Container Handling
Auto-Centering: Laser-guided alignment for 200L drums/IBCs
Gentle Grip: Vacuum/clamping hybrid system prevents container deformation
Leak Prevention: Automatic drip trays and spill containment systems
Safety & Compliance
ATEX Certification: Zone 2/22 options for flammable liquid handling
Emergency Recovery: Auto-ejects unstable loads without operator intervention
Load Testing: Real-time weight verification (±5kg accuracy)
Technical Specifications:
Container Types: 200L steel drums, plastic IBCs, composite totes
Pallet Size: 800×1200mm to 1600×1400mm (adjustable)
Cycle Rate: 450 containers/hour (single line) / 800 containers/hour (dual line)
Power: 22kW (3-phase AC380V/50Hz)
Air Consumption: 2.8m³/min (6bar)
Control System: 21.5" industrial PC with predictive maintenance dashboard
Industry Applications:
Chemical: Petrochemicals, solvents, and resin compound stacking
Food & Beverage: Edible oils, syrups, and liquid dairy products
Pharma: Bulk raw material handling for API production
Waste Management: Hazardous waste container consolidation
Why Choose Our 200L Palletizer?
Damage Reduction: 99.9% container integrity rate via smart gripping algorithms
Space Optimization: Vertical stacking reduces warehouse footprint by 60%
Labor Efficiency: Eliminates 4-6 operator roles per shift
ROI: Payback period as short as 8–12 months in high-throughput operations
Custom Solutions:
Cryogenic Configurations: -30°C operation for frozen liquid handling
Explosion-Proof: ATEX Zone 1/21 compliance for volatile environments
Multi-Line Integration: Synchronized operation with up to 6 input conveyors
Data Connectivity: API integration with ERP/WMS systems (SAP, Oracle, Infor)
