Fine Chemical Packaging Machine - 60KG Open-Mouth Bag Packaging Machine - 304 Stainless Steel Material Packaging Machine
Product Name
Fine Chemical Packaging Machine - 60KG Open-Mouth Bag Packaging Machine - 304 Stainless Steel Material
Key Specifications & Configurations
| Category | Details |
|---|---|
| Weighing Range | 15kg-2 tons/bag (Supports 60KG standard) |
| Packaging Speed | 20-30 bags/hour (Dynamic weighing accuracy ±0.2%) |
| Power Supply | 380V AC 50Hz, Total power 3-11kW |
| Air Pressure | 0.5-0.8MPa, Air consumption 0.02m³/sec |
| Material | 304 stainless steel (contact parts), corrosion-resistant & easy to clean |
| Dust Removal | Adjustable airflow 800-3000m³/min |
| Environmental | Temperature: -10°C~40°C, Humidity ≤80% |
| Optional Features | Pneumatic valve, ultrasonic sealing, screw/gravity feeding, auto thread cutting, touchscreen HMI |
Core Features
High Precision & Efficiency
Servo motor + screw feeding technology ensures ±0.2% dynamic weighing accuracy.
PLC control + Toledo high-sensitivity load cells for auto-calibration and error correction.
Smart & Flexible Design
Dual weighing hoppers (1.5x faster speed) + chain conveyor to prevent belt deviation.
Height-adjustable conveyor and photoelectric thread-cutting for labor savings.
Durability & Safety
Full 304 stainless steel structure + IP65 control cabinet for harsh environments.
Safety mechanisms: "No bag, no filling" and auto-shutdown for low air pressure.
Customization
Optional explosion-proof/vacuum systems, remote monitoring, and trade-in programs.
Applications
Industries: Fine chemicals, minerals, food, pharmaceuticals, agriculture.
Materials: Graphite powder/pellets, plastic resin, titanium dioxide, rice husk charcoal, ultrafine powders.
Operation Workflow
Setup: Manual bag placement → Container positioning.
Filling: High-speed filling (variable frequency) → Slow-speed topping.
Sealing: Auto sewing + pneumatic thread cutting → Conveyor output.
Monitoring: Real-time touchscreen data + fault diagnostics.
After-Sales Service
On-site Support: Free installation, training, and debugging.
Warranty: 1-year full coverage + lifetime maintenance.
Custom Solutions: Anti-corrosion, explosion-proof, and dust control systems.
